D-5

Scanner

2000 microEFM Appendix D

System Conguration

(Decimal)

(Hex) Description

Data

Type Access

1000 3E8 Product Code and Feature Privileges U16 RO

1001 3E9 Register Table Version U16 RO

1002 3EA Firmware Version U16 RO

1003 3EB Manufacture Date U16 RO

1004 3EC Sales Date U16 RO

1005 3ED Serial Number High U16 RO

1006 3EE Serial Number Low U16 RO

1007 3EF Sensor Serial Number[0] PA RO

1008 3F0 Sensor Serial Number[1] PA RO

1009 3F1 Sensor Serial Number[2] PA RO

1010 3F2 Sensor Serial Number[3] PA RO

1011 3F3 Sensor Serial Number[4] PA RO

1012 3F4 Sensor Serial Number[5] PA RO

1013 3F5 Expansion Board Manufacture Date U16 RO

1014 3F6 Expansion Board Sales Date U16 RO

1015 3F7 Expansion Board Serial Number High U16 RO

1016 3F8 Expansion Board Serial Number Low U16 RO

1017 3F9 Expansion Board Conguration U16 RO

Product Code

The Product Code is a read-only parameter used for identifying a Scanner 2000 device and its enabled

advanced features (such as PID controller and Modbus Master) using the ModWorX Pro software. This

parameter is dened at the factory.

Firmware Version/Register Table Version

The Firmware Version and Register Table Version numbers are set by the factory and are read-only. To

determine the version number, read the appropriate register and divide the value by 100. The general format

for version numbers is A.BC. For example the rmware register number is read as 0xA7 hexadecimal. This

represents the value 167 and a rmware version of 1.67.

Manufacture Date/Sales Date

These parameters are set at the factory and are read-only. These registers are formatted as MMYY. For

example, a value of 0908 represents the date September 2008.

Cameron Scanner 2000 microEFM User Manual
