Cameron Scanner 2000 microEFM User Manual

E-5
Scanner
®
2000 microEFM Appendix E
Table E.2—Transducer Block Parameters
Relative Parameter Denition
2043 GENERIC_USIGN32_
PARAM_2
Real Time On SC2000 (YYMM)
2044 GENERIC_USIGN32_
PARAM_3
Real Time On SC2000 (DDhh)
2045 GENERIC_USIGN32_
PARAM_4
Real Time On SC2000 (mmss)
2046 GENERIC_USIGN32_
PARAM_5
Not Used
2047 GENERIC_STRINGV_
PARAM_1
Not Used
2048 GENERIC_STRINGV_
PARAM_2
Not Used
Note The INDEX of AI block parameters in Table 3 contains a numeric prex that reects the AI block being
read. AI1 = 500, AI2 = 600, AI3 = 700, AI4 = 800. For example, the index for the parameter “ST_REV”
on AI block 1 will be 501 (the prex “500” plus the “1” shown in the table below).
Table E.3—Analog Input Block Parameters
Index Parameter Denition
xx0 NAME Block name and record member Information
xx1 ST_REV Revision level of the static data associated with the function block
xx2 TAG_DESC User description of the intended application of the block
xx3 STRATEGY Group identication number of the block
xx4 ALERT_KEY Identication number of the plant unit
xx5 MODE_BLK Mode of function block (ACTUAL, TARGET, PERMITTED, AND
NORMAL)
xx6 BLOCK_ERR Error status on hardware or rmware components related to this
block
xx7 PV Primary analog value used to execute a function, or a process
value associated with it
xx8 OUT Primary analog value calculated as a result of executing the
function
xx9 SIMULATE When enabled, allows transducer analog input or output to the
block to be manually supplied. When disabled, the simulate value
and status track the actual value and status.
x10 XD_SCALE Denes high and low scale values, engineering units code, and
number of digits to the right of the decimal point used with the
value obtained from the transducer for a specied channel
x11 OUT_SCALE Denes high and low scale values, engineering units code, and
number of digits to the right of the decimal point to be used in
displaying the OUT parameter and other parameters which have
the same scaling as OUT
x12 GRANT_DENY Options for controlling access of host computer and local control
panels to operating, tuning and alarm parameters of the block
