Cameron Scanner 2000 microEFM User Manual

E-3
Scanner
®
2000 microEFM Appendix E
Table E.1—Resource Block Parameters
Index Parameter Denition
435 UPDATE_EVT Alert generated by any change to the static data
436 BLOCK_ALM Alarm used for all conguration, hardware, connection failure or
system problems in the block. The cause of the alert is entered in
the subcode eld.
437 ALARM_SUM Current alert status, unacknowledged states, unreported states,
and disabled states of alarms associated with the function block.
438 ACK_OPTION Selection of whether alarms associated with the block will be
automatically acknowledged
439 WRITE_PRI Priority of the alarm generated by clearning the write lock.
440 WRITE_ALM This alert is generated if the write lock parameter is cleared.
441 ITK_VER Major revision number of the interoperability test case used in
certifying this device as interoperable.
442-464 Field Diagnostics NOTE: Field Diagnostics (FD) parameters are not currently
supported.
Table E.2—Transducer Block Parameters
Relative Parameter Denition
2000 NAME Block name and record member Information
2001 ST_REV Revision level of the static data associated with the function block
2002 TAG_DESC User description of the intended application of the block
2003 STRATEGY Group identication number of the block
2004 ALERT_KEY Identication number of the plant unit
2005 MODE_BLK Mode of function block (ACTUAL, TARGET, PERMITTED, AND
NORMAL)
2006 BLOCK_ERR Error status on hardware or rmware components related to this
block
2007 UPDATE_EVT Alert generated by any change to the static data
2008 BLOCK_ALM Alarm used for all conguration, hardware, connection failure or
system problems in the block. The cause of the alert is entered in
the subcode eld.
2009 TRANSDUCER_
DIRECTORY
Species the number and starting indicies of the transducers in
the transducer block
2010 TRANSDUCER_TYPE Type of transducer block
2011 XD_ERROR Error code for transducer error
2012 COLLECTION_
DIRECTORY
Species the number, starting indicies, and DD Item IDs of the
data collections in each transducer within a transducer block.
2013 PV_VALUE Value of Primary value parameter and its status
2014 PV_UNIT Enumerated unit for Primary value
2015 SV_VALUE Value of Secondary value parameter and its status
2016 SV_UNIT Enumerated unit for Secondary value
2017 TV_VALUE Value of Tertiary value parameter and its status
