A-7
Scanner
®
2000 microEFM Appendix A
Figure A.10—NuFlo USB adapter
Figure A.11—NuFlo USB adapter components
Using the Adapter
The CD supplied with the NuFlo USB Adapter contains the drivers required to enable USB communications
for a Scanner 2000 when the NuFLo USB Adapter is installed.
For step-by-step installation instructions, insert the CD in your computer and follow the instructions in the
NuFlo USB Adapter_Readme le. The software will install the appropriate driver that is compatible with your
computer’s operating system.
To complete installation and connect to a Scanner 2000, a user-supplied universal serial bus USB A/B cable is
required (Figure A.12).
Figure A.12—User-supplied USB A/B cable
When the software is fully installed, the adapter can be connected to the computer and used to connect to the
Scanner 2000 via ModWorX Pro (Tools/Select COM Port). For more information on ModWorX Pro, see the
ModWorX Pro User Manual, Part No. 9A-30165025.
