Cameron Scanner 2000 microEFM User Manual

D-24
Appendix D Scanner
®
2000 microEFM
Flow Run 1 Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
3233 CA1 FR1 Flow Coefcient 15 FP R/W 0.00
3235 CA3 FR1 Flow Coefcient 16 FP R/W 0.00
3237 CA5 FR1 Reynolds Number 1 FP R/W 1.00
3239 CA7 FR1 Reynolds Number 2 FP R/W 0.00
3241 CA9 FR1 Reynolds Number 3 FP R/W 0.00
3243 CAB FR1 Reynolds Number 4 FP R/W 0.00
3245 CAD FR1 Reynolds Number 5 FP R/W 0.00
3247 CAF FR1 Reynolds Number 6 FP R/W 0.00
3249 CB1 FR1 Reynolds Number 7 FP R/W 0.00
3251 CB3 FR1 Reynolds Number 8 FP R/W 0.00
3253 CB5 FR1 Reynolds Number 9 FP R/W 0.00
3255 CB7 FR1 Reynolds Number 10 FP R/W 0.00
3257 CB9 FR1 Reynolds Number 11 FP R/W 0.00
3259 CBB FR1 Reynolds Number 12 FP R/W 0.00
3261 CBD FR1 Reynolds Number 13 FP R/W 0.00
3263 CBF FR1 Reynolds Number 14 FP R/W 0.00
3265 CC1 FR1 Reynolds Number 15 FP R/W 0.00
3267 CC3 FR1 Reynolds Number 16 FP R/W 0.00
1
The Calibration Type register must be congured using ModWorX Pro. This register denes the type and
number of calibration points used. If altered manually, calibration points must be entered in ascending order.
Output Conguration
Register
(Decimal)
Register
(Hex)
Description
Data
Type
Access Default
4000 FA0 Pulse Out 1 - Source U16 R/W 16384
4001 FA1 Pulse Out 1 - Duration U16 R/W 10
4002 FA2 Pulse Out 1 - Decimal Location U16 R/W 2
4003 FA3 Pulse Out 1 - Data Pointer U16 R/W 108
4004 FA4 Pulse Out 1 - Scale Factor FP R/W 1
4006 FA6 Pulse Out 1 - Low Level FP R/W 0
4008 FA8 Pulse Out 1 - High Level FP R/W 0
4010 to 4039 Reserved
4040 FC8 Analog Out 1 - Source U16 R/W 0
4041 FC9 Analog Out 1 - Low Value FP R/W 0
4043 FCB Analog Out 1 - High Value FP R/W 1700
4045 FCD Analog Out 1 - Low Adjust U16 R/W 32768
4046 FCE Analog Out 1 - High Adjust U16 R/W 32768
4047 FCF Analog Out 2 - Source U16 R/W 0
4048 FD0 Analog Out 2 - Low Value FP R/W 0
4050 FD2 Analog Out 2 - High Value FP R/W 1700
4052 FD4 Analog Out 2 - Low Adjust U16 R/W 0
