D-15
Scanner
®
2000 microEFM Appendix D
Differential Pressure Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2418 972 DP - Units Scale Factor FP R/W 1.00
2420 974 DP - Units Offset Factor FP R/W 0.00
2422 976 DP - Unit Description 1 LCD R/W —
2423 977 DP - Unit Description 2 LCD R/W —
2424 978 DP - Unit Description 3 LCD R/W —
Differential Pressure Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2430 97E DP - Calibration Type
1
U16 R/W 0
2431 97F DP - Nominal Value FP R/W 1.00
2433 981 DP - Calibration Absolute Offset FP R/W 0.00
2435 983 DP - Calibration Actual 1 FP R/W 0.00
2437 985 DP - Calibration Actual 2 FP R/W 0.00
2439 987 DP - Calibration Actual 3 FP R/W 0.00
2441 989 DP - Calibration Actual 4 FP R/W 0.00
2443 98B DP - Calibration Actual 5 FP R/W 0.00
2445 98D DP - Calibration Actual 6 FP R/W 0.00
2447 98F DP - Calibration Actual 7 FP R/W 0.00
2449 991 DP - Calibration Actual 8 FP R/W 0.00
2451 993 DP - Calibration Actual 9 FP R/W 0.00
2453 995 DP - Calibration Actual 10 FP R/W 0.00
2455 997 DP - Calibration Actual 11 FP R/W 0.00
2457 999 DP - Calibration Actual 12 FP R/W 0.00
2459 99B DP - Calibration Measured 1 FP R/W 0.00
2461 99D DP - Calibration Measured 2 FP R/W 0.00
2463 99F DP - Calibration Measured 3 FP R/W 0.00
2465 9A1 DP - Calibration Measured 4 FP R/W 0.00
2467 9A3 DP - Calibration Measured 5 FP R/W 0.00
2469 9A5 DP - Calibration Measured 6 FP R/W 0.00
2471 9A7 DP - Calibration Measured 7 FP R/W 0.00
2473 9A9 DP - Calibration Measured 8 FP R/W 0.00
2475 9AB DP - Calibration Measured 9 FP R/W 0.00
2477 9AD DP - Calibration Measured 10 FP R/W 0.00
2479 9AF DP - Calibration Measured 11 FP R/W 0.00
2481 9B1 DP - Calibration Measured 12 FP R/W 0.00
1
The Calibration Type register must be congured using ModWorX Pro. This register denes the type and
number of calibration points used. If altered manually, calibration points must be entered in ascending order.
