Cameron Scanner 2000 microEFM User Manual

D-14
Appendix D Scanner
®
2000 microEFM
RTD Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2353 931 PT - Calibration Actual 10 FP R/W 0.00
2355 933 PT - Calibration Actual 11 FP R/W 0.00
2357 935 PT - Calibration Actual 12 FP R/W 0.00
2359 937 PT - Calibration Measured 1 FP R/W 0.00
2361 939 PT - Calibration Measured 2 FP R/W 0.00
2363 93B PT - Calibration Measured 3 FP R/W 0.00
2365 93D PT - Calibration Measured 4 FP R/W 0.00
2367 93F PT - Calibration Measured 5 FP R/W 0.00
2369 941 PT - Calibration Measured 6 FP R/W 0.00
2371 943 PT - Calibration Measured 7 FP R/W 0.00
2373 945 PT - Calibration Measured 8 FP R/W 0.00
2375 947 PT - Calibration Measured 9 FP R/W 0.00
2377 949 PT - Calibration Measured 10 FP R/W 0.00
2379 94B PT - Calibration Measured 11 FP R/W 0.00
2381 94D PT - Calibration Measured 12 FP R/W 0.00
1
The Calibration Type register must be congured using ModWorX Pro. This register denes the type and
number of calibration points used. If altered manually, calibration points must be entered in ascending order.
Differential Pressure Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2400 960 DP - Units
See Units Table
U16 R/W 401
2401 961 DP - Time Base
0 = Second
1 = Minute
2 = Hour
3 = Day
U16 R/W 0
2402 962 DP - Sampling Period (seconds) U16 R/W 1
2403 963 DP - Dampening Factor U16 R/W 0
2404 964 DP - Input Conguration U16 R/W 0
2405 965 DP - Override Enable
0 - Disabled
1 - Enabled
2 - Flow Dependent Averaging
U16 R/W 2
2406 966 DP - Override Value FP R/W 0.00
2408 968 DP - Fail Value FP R/W 0.00
2410 96A DP - Low Input Cutoff FP R/W 0.00
2412 96C DP - Low Flow Cutoff FP R/W 0.00
2414 96E DP - Sensor Range Low FP RO from MVT
2416 970 DP - Sensor Range High FP RO from MVT
