Cameron Scanner 2000 microEFM User Manual

D-13
Scanner
®
2000 microEFM Appendix D
RTD Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2300 8FC PT - Units
See Units Table
U16 R/W 501
2301 8FD PT - Time Base
0 = Second
1 = Minute
2 = Hour
3 = Day
U16 R/W 0
2302 8FE PT - Sampling Period (sec) U16 R/W 5
2303 8FF PT - Dampening Factor U16 R/W 0
2304 900 PT - Input Conguration U16 R/W 0
2305 901 PT - Override Enable
0 - Disabled
1 - Enabled
2 - Flow Dependent Averaging
U16 R/W 2
2306 902 PT - Override Value FP R/W 0.00
2308 904 PT - Fail Value FP R/W 60.00 Deg F
2310 906 PT - Low Input Cutoff FP R/W -100.00 Deg F
2312 908 PT - Low Flow Cutoff FP R/W -100.00
2314 90A PT - Sensor Range Low FP RO -40.00 Deg F
2316 90C PT - Sensor Range High FP RO 300.00 Deg F
2318 90E PT - Units Scale Factor FP R/W 1.80
2320 910 PT - Units Offset Factor FP R/W 32.00
2322 912 PT - Unit Description 1 LCD R/W —
2323 913 PT - Unit Description 2 LCD R/W —
2324 914 PT - Unit Description 3 LCD R/W —
RTD Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2330 91A
PT - Calibration Type
1
U16 R/W 0
2331 91B PT - Nominal Value FP R/W 1.00
2333 91D PT - Calibration Absolute Offset FP R/W 0.00
2335 91F PT - Calibration Actual 1 FP R/W 0.00
2337 921 PT - Calibration Actual 2 FP R/W 0.00
2339 923 PT - Calibration Actual 3 FP R/W 0.00
2341 925 PT - Calibration Actual 4 FP R/W 0.00
2343 927 PT - Calibration Actual 5 FP R/W 0.00
2345 929 PT - Calibration Actual 6 FP R/W 0.00
2347 92B PT - Calibration Actual 7 FP R/W 0.00
2349 92D PT - Calibration Actual 8 FP R/W 0.00
2351 92F PT - Calibration Actual 9 FP R/W 0.00
