D-12
Appendix D Scanner
®
2000 microEFM
Static Pressure Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2222 8AE SP - Unit Description 1 LCD R/W
2223 8AF SP - Unit Description 2 LCD R/W
2224 8B0 SP - Unit Description 3 LCD R/W
Static Pressure Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2230 8B6 SP - Calibration Type
1
U16 R/W 0
2231 8B7 SP - Nominal Value FP R/W 1.00
2233 8B9 SP - Calibration Absolute Offset FP R/W 0.00
2235 8BB SP - Calibration Actual 1 FP R/W 0.00
2237 8BD SP - Calibration Actual 2 FP R/W 0.00
2239 8BF SP - Calibration Actual 3 FP R/W 0.00
2241 8C1 SP - Calibration Actual 4 FP R/W 0.00
2243 8C3 SP - Calibration Actual 5 FP R/W 0.00
2245 8C5 SP - Calibration Actual 6 FP R/W 0.00
2247 8C7 SP - Calibration Actual 7 FP R/W 0.00
2249 8C9 SP - Calibration Actual 8 FP R/W 0.00
2251 8CB SP - Calibration Actual 9 FP R/W 0.00
2253 8CD SP - Calibration Actual 10 FP R/W 0.00
2255 8CF SP - Calibration Actual 11 FP R/W 0.00
2257 8D1 SP - Calibration Actual 12 FP R/W 0.00
2259 8D3 SP - Calibration Measured 1 FP R/W 0.00
2261 8D5 SP - Calibration Measured 2 FP R/W 0.00
2263 8D7 SP - Calibration Measured 3 FP R/W 0.00
2265 8D9 SP - Calibration Measured 4 FP R/W 0.00
2267 8DB SP - Calibration Measured 5 FP R/W 0.00
2269 8DD SP - Calibration Measured 6 FP R/W 0.00
2271 8DF SP - Calibration Measured 7 FP R/W 0.00
2273 8E1 SP - Calibration Measured 8 FP R/W 0.00
2275 8E3 SP - Calibration Measured 9 FP R/W 0.00
2277 8E5 SP - Calibration Measured 10 FP R/W 0.00
2279 8E7 SP - Calibration Measured 11 FP R/W 0.00
2281 8E9 SP - Calibration Measured 12 FP R/W 0.00
1
The Calibration Type register must be congured using ModWorX Pro. This register denes the type and
number of calibration points used. If altered manually, calibration points must be entered in ascending order.
