Cameron Scanner 2000 microEFM User Manual

D-11
Scanner
®
2000 microEFM Appendix D
Turbine 2 Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2153 869 T2 - Factor 10 FP R/W 1.00
2155 86B T2 - Factor 11 FP R/W 1.00
2157 86D T2 - Factor 12 FP R/W 1.00
2159 86F T2 - Frequency 1 FP R/W 1.00
2161 871 T2 - Frequency 2 FP R/W 1.00
2163 873 T2 - Frequency 3 FP R/W 1.00
2165 875 T2 - Frequency 4 FP R/W 1.00
2167 877 T2 - Frequency 5 FP R/W 1.00
2169 879 T2 - Frequency 6 FP R/W 1.00
2171 87B T2 - Frequency 7 FP R/W 1.00
2173 87D T2 - Frequency 8 FP R/W 1.00
2175 87F T2 - Frequency 9 FP R/W 1.00
2177 881 T2 - Frequency 10 FP R/W 1.00
2179 883 T2 - Frequency 11 FP R/W 1.00
2181 885 T2 - Frequency 12 FP R/W 1.00
1
The Calibration Type register must be congured using ModWorX Pro. This register denes the type and
number of calibration points used. If altered manually, calibration points must be entered in ascending order.
Static Pressure Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2200 898 SP - Units
See Units Table
U16 R/W 301
2201 899 SP - Time Base U16 R/W 0
2202 89A SP - Sampling Period U16 R/W 1
2203 89B SP - Dampening Factor U16 R/W 0
2204 89C SP - Input Conguration U16 R/W 1
2205 89D SP - Override Enable
0 - Disabled
1 - Enabled
2 - Flow Dependent Averaging
U16 R/W 2
2206 89E SP - Override Value FP R/W 0.00
2208 8A0 SP - Fail Value FP R/W 0.00
2210 8A2 SP - Low Input Cutoff FP R/W 0.00
2212 8A4 SP - Low Flow Cutoff FP R/W 0.00
2214 8A6 SP - Sensor Range Low FP RO from MVT
2216 8A8 SP - Sensor Range High FP RO from MVT
2218 8AA SP - Units Scale Factor FP R/W 1.00
2220 8AC SP - Units Offset Factor FP R/W 0.00
