Cameron Scanner 2000 microEFM User Manual

D-10
Appendix D Scanner
®
2000 microEFM
Turbine 2 Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2100 834 T2 - Units
See Units Table
U16 R/W 102 – BBL
2101 835 T2 - Time Base U16 R/W 3 – Day
2102 836 T2 - Sampling Period (sec) U16 R/W 5
2103 837 T2 - Dampening Factor U16 R/W 0
2104 838 T2 - Input Conguration
0 - TFM Low (20 mV @ <1000 Hz)
1 - TFM Med (50 mV @ <1000 Hz)
2 - TFM High (100 mV @ <1000 Hz)
3 - TFM Max (200 mV @ <1000 Hz)
4 - Pulse Input (on expansion board)
U16 R/W 1
2105 839 T2 - Override Enable
0 - Disabled
1 - Enabled
U16 R/W 0
2106 83A T2 - Override Value FP R/W 0.00
2108 83C T2 - Fail Value FP R/W 0.00
2110 83E T2 - Low Frequency Cutoff FP R/W 5.00
2112 840 T2 - Low Flow Cutoff FP R/W 0.00
2114 842 T2 - Sensor Range Low FP R/W 0.00
2116 844 T2 - Sensor Range High FP R/W 0.83333333
2118 846 T2 - Units Scale Factor FP R/W 0.02380952
2120 848 T2 - Units Offset Factor FP R/W 0.00
2122 84A T2 - Unit Description 1 LCD R/W —
2123 84B T2 - Unit Description 2 LCD R/W —
2124 84C T2 - Unit Description 3 LCD R/W —
Turbine 2 Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2130 852 T2 - Calibration Type
1
U16 R/W 1
2131 853 T2 - Linear Factor FP R/W 900.00
2133 855 T2 - Calibration Absolute Offset FP R/W 0.00
2135 857 T2 - Factor 1 FP R/W 900.00
2137 859 T2 - Factor 2 FP R/W 1.00
2139 85B T2 - Factor 3 FP R/W 1.00
2141 85D T2 - Factor 4 FP R/W 1.00
2143 85F T2 - Factor 5 FP R/W 1.00
2145 861 T2 - Factor 6 FP R/W 1.00
2147 863 T2 - Factor 7 FP R/W 1.00
2149 865 T2 - Factor 8 FP R/W 1.00
2151 867 T2 - Factor 9 FP R/W 1.00
