D-9
Scanner
®
2000 microEFM Appendix D
Turbine 1 Calibration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2030 7EE T1 - Calibration Type
1
U16 R/W 1
2031 7EF T1 - Linear Factor FP R/W 900.00
2033 7F1 T1 - Calibration Absolute Offset FP R/W 0.00
2035 7F3 T1 - Factor 1 FP R/W 900.00
2037 7F5 T1 - Factor 2 FP R/W 1.00
2039 7F7 T1 - Factor 3 FP R/W 1.00
2041 7F9 T1 - Factor 4 FP R/W 1.00
2043 7FB T1 - Factor 5 FP R/W 1.00
2045 7FD T1 - Factor 6 FP R/W 1.00
2047 7FF T1 - Factor 7 FP R/W 1.00
2049 801 T1 - Factor 8 FP R/W 1.00
2051 803 T1 - Factor 9 FP R/W 1.00
2053 805 T1 - Factor 10 FP R/W 1.00
2055 807 T1 - Factor 11 FP R/W 1.00
2057 809 T1 - Factor 12 FP R/W 1.00
2059 80B T1 - Frequency 1 FP R/W 1.00
2061 80D T1 - Frequency 2 FP R/W 1.00
2063 80F T1 - Frequency 3 FP R/W 1.00
2065 811 T1 - Frequency 4 FP R/W 1.00
2067 813 T1 - Frequency 5 FP R/W 1.00
2069 815 T1 - Frequency 6 FP R/W 1.00
2071 817 T1 - Frequency 7 FP R/W 1.00
2073 819 T1 - Frequency 8 FP R/W 1.00
2075 81B T1 - Frequency 9 FP R/W 1.00
2077 81D T1 - Frequency 10 FP R/W 1.00
2079 81F T1 - Frequency 11 FP R/W 1.00
2081 821 T1 - Frequency 12 FP R/W 1.00
1
The Calibration Type register must be congured using ModWorX Pro. This register denes the type and
number of calibration points used. If altered manually, calibration points must be entered in ascending order.
