Cameron Scanner 2000 microEFM User Manual

D-8
Appendix D Scanner
®
2000 microEFM
Archive Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
1418 58A Archive Field 11 U16 R/W T1 Run Time
1419 58B Archive Field 12 U16 R/W Unused
1420 58C Archive Field 13 U16 R/W Unused
1421 58D Archive Field 14 U16 R/W Unused
1422 58E Archive Field 15 U16 R/W Unused
1423 58F Archive Field 16 U16 R/W Unused
Turbine 1 Conguration
Register
(Decimal)
Register
(Hex) Description
Data
Type Access Default
2000 7D0 T1 - Units
See Units Table
U16 R/W 102 – BBL
2001 7D1 T1 - Time Base
0 = Second
1 = Minute
2 = Hour
3 = Day
U16 R/W 3
2002 7D2 T1 - Sampling Period (sec) U16 R/W 5
2003 7D3 T1 - Dampening Factor U16 R/W 0
2004 7D4 T1 - Input Conguration
0 - TFM Low (20 mV @ <1000 Hz)
1 - TFM Med (50 mV @ <1000 Hz)
2 - TFM High (100 mV @ <1000 Hz)
3 - TFM Max (200 mV @ <1000 Hz)
4 - Pulse Input
U16 R/W 1
2005 7D5 T1 - Override Enable
0 - Disabled
1 - Enabled
U16 R/W 0
2006 7D6 T1 - Override Value FP R/W 0.00
2008 7D8 T1 - Fail Value FP R/W 0.00
2010 7DA T1 - Low Frequency Cutoff FP R/W 5.00
2012 7DC T1 - Low Flow Cutoff FP R/W 0.00
2014 7DE T1 - Sensor Range Low FP R/W 0.00
2016 7E0 T1 - Sensor Range High FP R/W 0.833333333
2018 7E2 T1 - Units Scale Factor FP R/W 0.023809524
2020 7E4 T1 - Units Offset Factor FP R/W 0
2022 7E6 T1 - Unit Description 1 LCD R/W —
2023 7E7 T1 - Unit Description 2 LCD R/W —
2024 7E8 T1 - Unit Description 3 LCD R/W —
