Cameron Scanner 2000 microEFM User Manual

16
Section 1 Scanner
®
2000 microEFM
Table 1.1—Scanner 2000 microEFM Specications
Logging Daily records: 768 (>2 years)
Interval records:
• Adjustable from 5 sec to 12 hours
• 2304 (>3 months of 1-hour intervals) with main board
• 6392 (>8 months of 1-hour intervals) with main board and expansion
board
Event/alarm records: 1152
Records up to 16 user-dened parameters
Logs stored in non-volatile memory for up to 10 years
Memory Non-volatile memory for conguration and log data
256 KB standard
512 KB standard plus expansion board
Communications/
Archive Retrieval
RTU Modbus
®
• two on-board RS-485 communications ports (300 to 38.4K baud)
• full download from main board in approximately 3 minutes (approx. 6
minutes with expansion board)
Enron Modbus
®
compliant downloads
User-deneable Modbus
®
map with up to 25 oating point values
Explosion-proof control switch option
• Alternative to keypad controls (allows navigation of LCD views without
removing the enclosure lid)
• View next LCD display parameter
• View up to 99 daily logs on LCD
Explosion-proof communications adapter option
• External connector allows quick-connect to RS-485 COM ports without
removing the enclosure lid
• USB or RS-485 COM adapter installs in conduit opening
Flow Rate Calculations Natural Gas (Orice/NuFlo Cone):
AGA Report No. 3: Orice Metering of Natural Gas and Other Related
Hydrocarbon Fluids;
ISO 5167: Measurement of Fluid Flow by Means of Pressure Differential
Devices Inserted in Circular Cross-Section Conduits Running Full
NuFlo Cone Meter User Manual, www.c-a-m.com (Measurement Systems
Division page)
Natural Gas (Turbine Meter):
AGA Report No. 7: Measurement of Natural Gas by Turbine Meters
Natural Gas (Averaging Pitot Tube Meter):
ASME MFC-12M-2006: Measurement of Fluid Flow in Closed Conduits
Using Multiport Averaging Pitot Primary Elements
Steam (Orice/NuFlo Cone):
AGA Report No. 3: Orice Metering of Natural Gas and Other Related
Hydrocarbon Fluids;
ISO 5167: Measurement of Fluid Flow by Means of Pressure Differential
Devices Inserted in Circular Cross-Section Conduits Running Full
NuFlo Cone Meter User Manual, www.c-a-m.com (Measurement Systems)
Liquids (Turbine):
API Manual of Petroleum Measurement Standards, Chapter 5, Section 3,
Measurement of Liquid Hydrocarbons by Turbine Meters
