Cameron Scanner 2000 microEFM User Manual

D-46
Appendix D Scanner
®
2000 microEFM
Bit Denitions—Alarms and Diagnostics
Bit
Flow Run
Alarm High
Flow Run
Alarm Low Diagnostic 1 Diagnostic 2 Diagnostic 3 Diagnostic 4
2 FRA3 High FRA3 Low PT Override PT Low
MVT User
Parameter
CRC fail
Reserved
1 FRA2 High FRA2 Low A1 Override A1 Low
MVT Factory
Parameter
CRC fail
Device Seal
0 FRA1 High FRA1 Low A2 Override A2 Low
MVT Not
Present
Ext. Switch
The Scanner 2000 produces low, high and fail conditions for the inputs (not the ow alarms) in accordance
with the following table.
Status Range Check
Low Lower Range Limit - 20% of span
Fail Low Lower Range Limit - 500% of span
High Upper Range Limit + 20% of span
Fail High Upper Range Limit + 500% of span
Units of Measurement
Value Units Scale Offset
101 GAL - BASE 1.000000000000 0.00
102 BBL 0.023809523810 0.00
103 M3 0.003785411780 0.00
104 LIT 3.785411784000 0.00
105 CF 0.133680555560 0.00
106 ACF 0.133680555560 0.00
107 ACM 0.003785411780 0.00
201 MCF - BASE 1.000000000 0.00
202 SCF 1000.000000000 0.00
203 M3 28.316846592 0.00
204 GAL 7480.519480271 0.00
205 BBL 178.107606673 0.00
207 LIT 28316.846592000 0.00
301 PSIG - BASE 1.00000000 0.00
302 Pa 6894.75729317 0.00
303 Kpa 6.89475729317 0.00
304 Mpa 0.00689475729317 0.00
305 Bar 0.06894757 0.00
306 In H2O 27.70500000 0.00
401 In H2O - BASE 1.000000000000 0.00
402 Pa 248.641080600000 0.00
403 Kpa 0.248641080600 0.00
