Section 1 Scanner
®
2000 microEFM
Table 1.1—Scanner 2000 microEFM Specications
MVT Accuracy Effect on differential pressure for a 100-psi change in static pressure:
SP/SWP
(PSIA)
DP
(IN H2O)
Max.
Overrange
(PSIA) Zero Shift Span Shift
100 30 150 ±0.05% of URL ±0.01% of reading
300 200 450 ±0.007% of URL ±0.01% of reading
840 ±0.002% of URL ±0.01% of reading
500 200 750 ±0.010% of URL ±0.01% of reading
1500 200 2250 ±0.010% of URL ±0.01% of reading
300 ±0.004% of URL ±0.01% of reading
400 ±0.004% of URL ±0.01% of reading
840 ±0.004% of URL ±0.01% of reading
3000* 200 4500 ±0.010% of URL ±0.01% of reading
300 ±0.004% of URL ±0.01% of reading
400 ±0.004% of URL ±0.01% of reading
840 ±0.004% of URL ±0.01% of reading
5300* 200 7420 ±0.010% of URL ±0.01% of reading
300 ±0.004% of URL ±0.01% of reading
400 ±0.004% of URL ±0.01% of reading
840 ±0.004% of URL ±0.01% of reading
* 3000-psia and 5000-psia ranges have not been evaluated by Measurement Canada
Inputs (Main Board) Process Temperature Input
• 100-ohm platinum RTD with 2-wire, 3-wire, or 4-wire interface
• Sensing Range: -40°C to 427°C (-40°F to 800°F)
• Accuracy: 0.2°C (0.36°F) over sensing range at calibrated temperature
• Temperature effect: 0.3°C over operating range of -40°C to 70°C (0.54°F
over operating range of -40°F to 158°F)
• Resolution: 24 bits
• User-adjustable sample time and damping
Turbine Meter Input 1
• Congurable sensitivity adjustment (20, 50, 100 or 200 mV, peak-to-peak)
• Frequency range: 0 to 3500 Hz
• Input amplitude: 20 mV to 3000 mV, peak to peak
Turbine Setting Input Sensitivity
0 – 1000 Hz 1000 – 2000 Hz 2000 – 3500 Hz
Low (20mV) 20 mVpp 25 mVpp 50 mVpp
Med (50mV) 50 mVpp 70 mVpp 110 mVpp
High (100mV) 100 mVpp 150 mVpp 250 mVpp
Max (200mV) 200 mVpp 380 mVpp 620 mVpp

Cameron Scanner 2000 microEFM Specifications
