To connect the Scanner 2000 to a turbine meter using this method, perform the following steps:
1. Position the Scanner 2000 and pickup extension assembly above the owmeter.
2. Plug the Scanner 2000 cable connector into the magnetic pickup of the turbine meter and hand-tighten the
knurled nut on the connector.
3. Screw the Scanner 2000/pickup extension assembly onto the owmeter threads surrounding the magnetic
pickup with the display facing the desired direction, and tighten.
CAUTION Do not use Teon
®
tape on the threads of the union, adapter, or pipe plugs. Use of
Teon
®
tape will void the explosion-proof rating of the instrument.
4. Install the RTD assembly in the thermowell. Remove the plug from a conduit opening in the top of the
Scanner 2000 enclosure, route the RTD assembly cable through the conduit opening and connect it to the
main circuit board. A wiring diagram for the RTD assembly is provided in Figure 3.5, page 66.For hazard-
ous areas, review Hazardous Area Installations, page 27.
