Chroma 62000D Series User Manual

Programmable Bidirectional DC Power Supply 62000D Series
Operating and Programming Manual
5-6
CONFigure:APGVMeas
Sets the action type of APG VMEAS.
CONFigure:APGISet
Sets the action type of APG SOURCE /
LOAD ISET.
CONFigure:APGIMeas
Sets the action type of APG IMEAS.
CONFigure:AVG:TIMES
Sets the average times for measuring
voltage/current.
CONFigure:AVG:METHod
Sets the average method for measuring
voltage/current.
CONFigure:BRIGhtness
Sets the display brightness of panel.
CONFigure:MSTSLV:ID
Sets the device to Master .
CONFigure:MSTSLV:PARSER
Sets to series or parallel mode.
CONFigure:MSTSLV:NUMSLV
Sets the number of SLAVE to be
controlled.
CONFigure:MSTSLV:READY?
Queries the Master/Slave connection
status.
CONFigure:MSTSLV
Executes the Master/Slave control.
CONFigure:INHibit
Executes the Remote Inhibit control.
CONFigure:INHibit:PULL
Executes the Remote Inhibit input signal to
enhance the resistance control.
CONFigure:INTERLOCK
Executes the Safety Interlock control.
CONFigure:INTERLOCK:PULL
Executes the Safety Interlock input signal
to enhance the resistance control.
CONFigure:EXTON
Executes the External ON/OFF control.
CONFigure: EXTON:PULL
Executes the External ON/OFF input signal
to enhance the resistance control.
SOURce:VOLTage
Sets the output voltage.
SOURce:VOLTage:LIMit:{HIGH/LOW}
Sets the output voltage range.
SOURce:VOLTage:PROTect:HIGH
Sets the voltage range for over voltage
protection.
SOURce:VOLTage:SLEW
Sets the rising or falling slew rate (volt/ms)
of output voltage.
SOURce: CURRent
Sets the output current (ampere).
SOURce:CURRent:LIMit:{HIGH/LOW}
Sets the output current range.
SOURce:CURRent:PROTect:HIGH
Sets the current range for over current
protection.
SOURce:CURRent:SLEW
Sets the rising or falling slew rate (amp/ms)
of output current.
SOURce:POWer
Sets the output power.
SOURce:POWer:LIMit:{HIGH/LOW}
Sets the output power range.
SOURce:POWer:PROTect:HIGH
Sets the power range for over power
protection.
SOURce:DCON:{RISE/FALL}
Sets the DC_ON signal active point.
LOAD: CURRent
Sets the Load output current.
LOAD:CURRent:PROTect:HIGH
Sets the current range for Load over
current protection.
LOAD:POWer
Sets the Load power output.
LOAD:POWer:PROTect:HIGH
Sets the power range for Load over power
protection.
FETCh:VOLTage?
Measures the output of power supply and
returns real time voltage.
