171
READER SETTINGS TABLE
The tables below list reader settings as well as symbology settings for the 2D scan
engine.
2D Engine
Description Default
Decode Time-out Set the maximum time for decoding to continue during a
scan attempt.
1~9 (second)
3 sec.
Decode Illumination Decide whether to flash illumination on every barcode
capture to aid decoding.
Turn On (Internal LED)
Turn Off
On
Aiming Pattern Decide whether to project the aiming pattern during
barcode capture.
Turn On
Turn Off
On
Redundancy Level Level 1
Level 1
he following barcodes must be successfully read twice before being
decoded:
Barcode Types Code Length
Codabar 8 characters or less
MSI 4 characters or less
Industrial 25 (Discrete 25) 8 characters or less
Interleaved 25 8 characters or less
Level 2 All barcodes must be successfully read twice before being decoded.
Level 3 All barcodes except for the following barcodes must be successfully read
twice before being decoded.
The following barcodes must be read three times:
Barcode Types “Excluded” Code Length
Codabar 8 characters or less
MSI 4 characters or less
Industrial 25 (Discrete 25) 8 characters or less
Interleaved 25 8 characters or less
Appendix III
2D IMAGER
