CipherLab 9600 - Symbology Settings Table

166
9600 Mobile Computer Reference Manual
SYMBOLOGY SETTINGS TABLE
CCD/Laser Engine Description Default
Codabar Enable
Select Start/Stop
Characters
If "Transmit Start/Stop Characters" is desired, select one
set:
 abcd / abcd
 abcd / tn*e
 ABCD / ABCD
 ABCD / TN*E
abcd / abcd
Transmit Start/Stop
Characters
Decide whether to include the start/stop characters in the
data being transmitted.
No
Code 128 Enable
GS1-128 (EAN-128) Enable
Transmit Code ID
Decide whether to include Code ID (“]C1”) will be included
in the data being transmitted.
No
Replace Field
Separator
Decide whether to replace the field separator. If the
barcode contains Field Separator “0x1D”, it will be
changed to the desired Field Separator. For example, type
the desired character “;” (semicolon) as the new field
separator. Then if the barcode contains Field Separator
“0x1D”, it will be changed to “;”.
No
ISBT 128 Enable
Industrial 25 (Discrete 25) Enable
Start/Stop Selection This decides the readability of all 2 of 5 symbology
variants. For example, flight tickets actually use an
Industrial 25 barcode but with Interleaved 25 start/stop
pattern. In order to read this barcode, the start/stop
pattern selection parameter of Industrial 25 should set to
"Interleaved 25".
Industrial 25
Verify Check Digit Decide whether to verify the check digit. If the check digit
is incorrect, the barcode will not be accepted.
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
Select Length
 One or two fixed lengths
 Range
4~127
Interleaved 25 Enable
Start/Stop Selection Refer to Industrial 25. Interleaved
25
Verify Check Digit Decide whether to verify the check digit. If the check digit
is incorrect, the barcode will not be accepted.
No
Transmit Check Digit Decide whether to include the check digit in the data being
transmitted.
Yes
