182
9600 Mobile Computer
Reference Manual
Select JPEG Size Set a value from 5 to 150, which represents the file size in
multiples of 1024 bytes (1K). For example, setting this
value to 8 permits the file size to be as large as 8192
bytes.
40
Bits per Pixel Select the number of significant bits per pixel (BPP) to use
when capturing an image.
1 bit per pixel (for black and white images)
4 BPP (to assign 1 of 16 levels of grey to each pixel)
8 BPP (to assign 1 of 256 levels of grey to each pixel)
8
Default image store By default, the captured image is stored under the
directory “\DiskOnChip\images” in the format of YYMMDD
HHMMSS.jpg or YYMMDDHHMMSS.bmp.
If you want to change the directory, tap [Browse].
\DiskOnChip\
images
Note: (1) For JPEG files, these BPP settings are ignored for it always uses 8 bits per pixel!
(2) When the image capture feature is enabled, press the [SCAN] button and it will
capture an image instead of reading a barcode.
Miscellaneous Options ---
Transmit Code ID Decide whether to include AIM Code ID in the beginning of
data. Each AIM Code ID contains the three-character string
“]cm” –
] = Flag Character (ASCII 93)
c = Code Character (see below)
m = Modifier Character (see below)
Disable
