• dfbit
• ipv4 source
• pmtu
• sequencing
• transport-mode
Step 4 encapsulation l2tpv3
Example:
RP/0/RSP0/CPU0:router (config-l2vpn-pwc)# encapsulation l2tpv3
Sets pseudowire encapsulation to L2TPv3
Step 5 protocol l2tpv3
Example:
RP/0/RSP0/CPU0:router (config-l2vpn-pwc-encap-l2tpv3)# protocol l2tpv3
Sets pseudowire signaling protocol to L2TPv3.
Step 6 Use the commit or end command.
commit - Saves the configuration changes and remains within the configuration session.
end - Prompts user to take one of these actions:
• Yes - Saves configuration changes and exits the configuration session.
• No - Exits the configuration session without committing the configuration changes.
• Cancel - Remains in the configuration mode, without committing the configuration changes.
Configuring Source IPv6 address for L2TPv3 over IPv6 tunnel
Perform this task to configure the source IPv6 address for the L2TPv3 over IPv6 tunnel.
SUMMARY STEPS
1. configure
2. l2vpn
3. xconnect group group-name
4. p2p xconnect-name
5. interface type interface-path-id
6. neighbor ipv6 peer-address pw-id pseudowire-id
7. source pw-source-address
8. end or commit
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
154
Implementing Point to Point Layer 2 Services
Configuring Source IPv6 address for L2TPv3 over IPv6 tunnel
