RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd-ac)#interface GigabitEthernet0/5/0/1.15
Adds an interface to a bridge domain that allows packets to be forwarded and received from other interfaces that are part
of the same bridge domain. The interface now becomes an attachment circuit on this bridge domain.
Step 7 pbb edge i-sid service-id core-bridge core-bridge-name
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd)#pbb edge i-sid 1000 core-bridge pbb-core
Configures the bridge domain as PBB edge with the service identifier and the assigned core bridge domain and enters
the PBB edge configuration submode.
This command also creates the Virtual instance port (VIP) that associates the PBB Edge bridge domain to the specified
Core bridge domain.
All the interfaces (bridge ports) under this bridge domain are treated as the customer network ports (CNP).
Step 8 static-mac-address cda-mac-address bmac bda-mac-address
Example:
RP/0/RSP0/CPU0:router(config-l2vpn-bg-bd-pbb-edge)#static-mac-address 0033.3333.3333 bmac 0044.4444.4444
Configures the static CMAC to BMAC mapping under the PBB Edge submode.
Step 9 Use the commit or end command.
commit - Saves the configuration changes and remains within the configuration session.
end - Prompts user to take one of these actions:
• Yes - Saves configuration changes and exits the configuration session.
• No - Exits the configuration session without committing the configuration changes.
• Cancel - Remains in the configuration mode, without committing the configuration changes.
Configuring PBB VPLS
Perform these tasks to configure PBB VPLS:
Configuring Access Pseudowire in I-Component
Perform this task to configure the static MAC addresses under the PBB edge bridge domain.
SUMMARY STEPS
1. configure
2. l2vpn
3. bridge group bridge-group-name
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
382
Implementing IEEE 802.1ah Provider Backbone Bridge
Configuring PBB VPLS
