Configures EVPN address family.
Step 7 import re-originate stitching-rt
Example:
RP/0/RSP0/CPU0:router(config-bgp-nbr-af)# import re-originate stitching-rt
Enables import of routing information from BGP EVPN NLRIs that have route target identifier matching the stitching
route target identifier, and exports this routing information after re-origination to the L2VPN BGP neighbor.
Step 8 advertise l2vpn evpn re-originated
Example:
RP/0/RSP0/CPU0:router(config-bgp-nbr-af)# advertise l2vpn evpn re-originated
Configures the advertisement of L2VPN EVPN routes to be received from the L2VPN BGP neighbor.
Step 9 Use the commit or end command.
commit - Saves the configuration changes and remains within the configuration session.
end - Prompts user to take one of these actions:
• Yes - Saves configuration changes and exits the configuration session.
• No- Exits the configuration session without committing the configuration changes.
• Cancel - Remains in the configuration mode, without committing the configuration changes.
Configure Network Virtualization Endpoint (NVE) Interface
Perform this task to create an NVE interface and configure it as a VXLAN Tunnel EndPoint (VTEP) for
VxLAN.
SUMMARY STEPS
1. configure
2. interface nve nve-identifier
3. source-interface loopback loopback-interface-identifier
4. anycast source-interface loopback loopback-interface-identifier
5. redundancy
6. backbone vxlan
7. iccp group group number
8. exit
9. backbone mpls
10. iccp group group number
11. exit
12. exit
13. member vni vni_number
14. load-balance per-evi
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
508
EVPN Features
Configure Network Virtualization Endpoint (NVE) Interface
