Step 16 (Optional) timers
Example:
RP/0/RSP0/CPU0:router(config-evpn-ac)# timers
Configures per Ethernet segment timers.
Step 17 (Optional) peering seconds
Example:
RP/0/RSP0/CPU0:router(config-evpn-ac-timers)# peering 15
Configures the interface specific peering timer. Default is 3 seconds. Range is 0 to 300 seconds.
Step 18 (Optional) recovery seconds
Example:
RP/0/RSP0/CPU0:router(config-evpn-ac-timers)# recovery 30
Configures the interface specific recovery timer. Default is 30 seconds. Range is 20 to 3600 seconds.
Step 19 Use the commit or end command.
commit - Saves the configuration changes and remains within the configuration session.
end - Prompts user to take one of these actions:
• Yes - Saves configuration changes and exits the configuration session.
• No - Exits the configuration session without committing the configuration changes.
• Cancel - Remains in the configuration mode, without committing the configuration changes.
Configure EVPN Service Instance (EVI) Parameters
Perform this task to define EVPN service instance (EVI) parameters.
SUMMARY STEPS
1. configure
2. evpn
3. evi evi_id
4. bgp
5. (Optional) rd { 2-byte as_number | 4-byte as_number | IP_address | none } : { nn }
6. (Optional) route-target import { 2-byte as_number | 4-byte as_number | IP_address | none } : {
nn }
7. (Optional) route-target export { 2-byte as_number | 4-byte as_number | IP_address | none } : {
nn }
8. exit
9. advertise-mac
L2VPN and Ethernet Services Configuration Guide for Cisco ASR 9000 Series Routers, IOS XR Release 6.3.x
536
EVPN Features
Configure EVPN Service Instance (EVI) Parameters
