Chapter 1 Specifications
1-1. General Specifications
CL-E700 series 1-6
Control language
Conforms to Datamax
®
programming language and Zebra
®
programming language
Outline of electronic devices
CPU ARM
®
Cortex
TM
-A9 (Max. operating frequency: 400 MHz)
ROM FLASH ROM 16MByte (User area: 4MByte)
RAM SDRAM 32MByte (User area: 4MByte)
Media detection sensors
Transparent sensor Detects media gap between labels, notches on tags, and media out.
Reflective sensor Detects reflective mark on back of media and media out.
Ribbon tension sensor Detects tension/slack of ink ribbon.
Ribbon encoder sensor Detects running of ink ribbon, and ink ribbon out.
Label peeling sensor *
1
Detects labels that are peeled off.
Communication interfaces
USB Conforms to USB2.0 (High speed 480Mbps / Full speed 12Mbps)
Wired LAN 100BASE-TX / 10BASE-T
Communication interface (Options)
Serial 2400 4800 9600 19200 38400 57600 115200 bps
Parallel IEEE1284 (Compatible, Nibble, ECP mode)
Network Multi-functional Ethernet (10BASE-T / 100BASE-TX)
Standard Wi-Fi(1) (IEEE802.11n / IEEE802.11g / IEEE802.11b)
Standard Wi-Fi(2) (IEEE802.11n / IEEE802.11a / IEEE802.11g /
IEEE802.11b)
Multi-functional Wi-Fi (IEEE802.11n / IEEE802.11g / IEEE802.11b)
Indications and switches
LCD Displays instructions for operation and settings. Also displays an
error.
LED Power ON (green), Error (red)
Buzzer Alarms, errors, etc.
Operating panel keys PAUSE, FEED, STOP, MENU
Head-up detection
sensor
Detects head open.
Power switch Turns power on and off.
Power supply
100V to 240V, 50/60Hz Power supply voltage/
frequency
UL60950-1st/2nd Edition, CSA No. 950, FCC Part 15 Subpart B
(Class A)
EN60950-1, EN55022 (Class A), EN55024, EN61000-3-2,
EN61000-3-3
GB4943.1-2011, GB9254-1998, GB17625.1-2003
Power consumption 100V:
72W (operating at 6 IPS at 12.5% printing duty), 2.9W (standby)
230V:
65W (operating at 6 IPS at 12.5% printing duty), 2.6W (standby)
