Citizen CL-E700 Series Technical Manual

Chapter 2 Operating Principles
2-2. Operation of Control Parts
CL-E700 series 2-22
2-2-3. Memory map
00000000h
FPGA
000000FFh
I/O
0C000000h
SDRAM
32M Bytes
0DFFFFFFh
RAM Downloading Area (4M Bytes)
Image Buffer
Others
18000000h
1802FFFFh
Boot Loader
18030000h
1834FFFFh
Firmware
18350000h
1874FFFFh
ROM Downloading Area (4M Bytes)
18760000h
1879FFFFh
FPGA Data
187A0000h
187AFFFFh
Setting Information
(User Settings)
Serial Flash ROM
187B0000h 16M Bytes
187BFFFFh
Setting Information
(Factory-set Settings)
187C0000h
187CFFFFh
LCD Character Data (For downloading)
(For CSA/CSE)
187D0000h
187DFFFFh
LCD Font Data (For downloading)
(For CSA/CSE)
187E0000h
187EFFFFh
Service Information (Backup)
187F0000h
187FFFFFh
Service Information
18800000h
18FFFFFFh
Chinese Font (8M Bytes)
20000000h
202FFFFFh
Command RAM/Data RAM
(Built-in CPU)
CPU
20300000h
FFFFFFFFh
I/O (Built-in CPU)
Reserved Area
