Citizen CL-E700 Series Technical Manual

Chapter 3 Disassembly and Maintenance
3-7. Adjustments
CL-E700 series 3-50
3-7. Adjustments
3-7-1. Transparent/Reflective Sensor Adjustment
When one of the following parts is replaced with a new one, perform sensor position adjustment
and sensor sensitivity adjustment as shown in the table below.
Parts replaced Sensor position adjustment Sensor sensitivity adjustment
SA Main PCB Through Pos, Reflect Pos Init Thru Sen, Init Refl Sen
SA TRA Sen PCB
(Transparent sensor)
Through Pos Init Thru Sen
SA Ref Sensor PCB
(Reflective sensor)
Reflect Pos Init Thru Sen, Init Refl Sen
(1) Sensor position adjustment (Factory mode)
In Factory mode, perform the following sensor position adjustment. For the adjustment
procedure, r
efer to the following “Refer to” column.
Submenu Adjust when the following part is replaced. Refer to
Through Pos • SA TRA Sen PCB (Transparent sensor)
• SA Main PCB
Reflect Pos • SA Ref Sensor PCB (Reflective sensor)
• SA Main PCB
“2-3-3. Factory/Service
mode” in Chapter 2
(2) Sensor sensitivity adjustment (Factory mode)
• Since Factory mode
menu includes essential items that can affect the
printing accuracy, etc, DO NOT change the factory set values unless
otherwise required.
• Do not turn OFF the power of the printer until you finish the adjustment. If
the power is turned OFF before finishing, you need to repeat the
adjustment from the beginning.
• The value adjusted here is retained until you change it with the same
procedure. Even if you perform initialization by selecting “Test Mode” main
menu, “Factory Default” submenu and then “Yes”, the changed value here
does not return to the initial value set at the factory.
Perform the sensitivity adjustment for each sensor with the following submenu. For the
adjustment procedure, refer to the following “Refer to” column.
Submenu Adjust when the following part is replaced. Refer to
Init Thru Sen • SA TRA Sen PCB (Transparent sensor)
• SA Ref Sensor PCB (Reflective sensor)
• SA Main PCB
“3-7-1(2-1) “Init Thru Sen”
sensitivity adjustment”
Init Refl Sen • SA Ref Sensor PCB (Reflective sensor)
• SA Main PCB
“3-7-1(2-2) Init Refl Sen
sensitivity adjustment”
