Citizen CL-E700 Series Technical Manual

Chapter 2 Operating Principles
2-4. Interface
CL-E700 series 2-66
2-4. Interface
2-4-1. USB Interface
(1) Specifications
Standards Complies with Universal Serial Bus 2.0 Specification
Transmission speed Compatible with 480 Mbps (high-speed) transmission and 12Mbps
(full speed) transmission
Receive buffer 16K bytes
Connector DUSB 15120-00400 (KST)
(2) Signal line and pin arrangement
Pin No. Signal code Signal Function
1 VBUS USB power USB power (+5V)
2 D- Signal line - - signal line
3 D+ Signal line + + signal line
4 GND GND GND
2-4-2. Wired LAN Interface
(1) Specifications
Supporting protocols Network layer: ARP, IP, TCP
Transport layer: TCP, UDP
Application layer: DHCP, HTTP, SNMP, Raw Socket Port
Connector RJ-45
(2) Signal line and pin arrangement
Pin No. Signal name Function
1 TX+ Send (+)
2 TX- Send (-)
3 RX+ Receive (+)
4 NC Not used.
5 NC Not used.
6 RX- Receive (-)
7 NC Not used.
8 NC Not used.
