Citizen CL-E700 Series Technical Manual

Chapter 5 Parts Lists
CL-E700 series 5-4
PARTS LIST for CL-E700 series TITLE: Recommended Spare Parts List Sheet No. 1/1
Rev. No. 0
Maint. Class
Item
No.
Location Part No. Part Name
Q'ty/
Unit
Worn Casual
Remarks @
1 2-8 PWT20011-0 Unit Power Supply 1
2 2-13-1 PPS00152-0 SA Main PCB (200ENG) 1 For CSA/CSE
3 2-13-2 PPS00218-0 SA Main PCB (200CHN) 1
For CHINA
4 2-13-3 PPS00219-0 SA Main PCB (200ASIA) 1 For ASIA
5 3-9 PPK90020-0 SA Platen 1
6 4-6 PPM80015-0 SA Head (200dpi) 1
7 5-1 PPF80010-0 SA PF Motor (with Thermistor) 1
8 5-11 JM66730-1 SA Ref Sensor PCB 1
9 6-1 JM66715-1 SA Head Up Sensor PCB 1
10 6-10 JM66725-0 SA TRA Sen PCB 1
11 8-1 PPG30002-0 SA Ribbon Tension Unit R 1
12 8-5 PPS00161-0 SA Ribbon Control PCB 1
13 8-6 PPF80004-0 SA Ribbon Motor F 1
14 8-14 PPS90029-0 SA Ribbon Sensor 1
15 8-21 PPS90030-0 SA Ribbon Encoder 1
16
17
18
19
20
