Citizen CL-E700 Series

Chapter 5 Parts Lists
5-7 CL-E700 series
PARTS LIST for CL-E700 series TITLE: General Assembly Sheet No. 1/2
Drawing No. 1 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
1-1 SA Ribbon Holder JM34710-1 2
-2 Unit Ribbon - 1 (Ref. Drawing No. 8)
-3 Cover PF Motor 2 PBA00100-0 1
-4 Cover Front PBA00094-0 1
-5 Case PBA00093-0 1
-6 Logo Citizen L PAX30002-0 1
-7 Cover Front Top PBA00096-0 1
-8 Cover Window PRC70011-0 1
-9 SA Top Cover PPA00038-0 1
-10 Cover Hinge JN56209-0 2
-11 Hinge JN59909-0 2
-12 Plate Hinge L PAC70075-0 1
-13 Cover Steel Rear PAA00008-0 1
-14 Cover Lever PAC80001-0 1
-15 Spring Damper PJG60007-0 2
-16 SA Damper Shaft PPG40002-0 1
-17 Plate Holder Paper L PAC70072-0 1
-18 Plate Hinge R PAC70076-0 1
-19 Cover Steel R PAA00007-0 1
-20 Cover PF Motor PBA00097-0 1
