Citizen CL-E700 Series

Chapter 5 Parts Lists
5-11 CL-E700 series
PARTS LIST for CL-E700 series TITLE: Unit Base Sheet No. 1/2
Drawing No. 2 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
2-1 Unit Mechanism - 1 (Ref. Drawing No. 3)
-2 Frame Mechanism PAC60059-0 1
-3 SA Relay PCB PPS00158-0 1
-4 Frame Relay PCB PAC60060-0 1
-5 SA Relay Cable PPS30047-0 1
-6 Cover Power PCB PAC80021-0 1
-7 SA Power Cable PPS30049-0 1
-8 Unit Power Supply PWT20011-0 1
-9 Sheet Insulation Power PCB PRC00016-0 1
-10 Plate Power PCB PAC70071-0 1
-11 Plate I/F Cover TA54107-1 1
-12 Plate Main PCB PAC70074-0 1
-13-1 SA Main PCB (200ENG) PPS00152-0 1 For CSA, CSE
-13-2 SA Main PCB (200CHN) PPS00218-0 1 For CHINA
-13-3 SA Main PCB (200ASIA) PPS00219-0 1 For ASIA
-14 SA Power SW Cable PPS30050-0 1
-15 Cover Plate Inlet PBC80048-0 1
-16 Plate Inlet PAC70078-0 1
-17 Frame Bottom PAA00005-0 1
-18 Leg PWA10002-0 4
