Citizen CL-E700 Series Technical Manual

Chapter 5 Parts Lists
5-15 CL-E700 series
PARTS LIST for CL-E700 series TITLE: Unit Mechanism Sheet No. 1/1
Drawing No. 3 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
3-1 Shaft Head Holder JM42007-0 1
-2 Unit Head - 1 (Ref. Drawing No. 4)
-3 Label Heat Caution TZ99981-0 1
-4 Label Head Balance JM99981-0 1
-5 Label Head Adjust JM99982-0 1
-6 Spring Head Up JM13601-0 1
-7 Spring2 Head Up JM13605-0 1
-8 Hook Head Up Spring 2 JM14112-0 1
-9 SA Platen PPK90020-0 1
-10 Unit PF - 1 (Ref. Drawing No. 5)
-11 Unit Sensor U - 1 (Ref. Drawing No. 6)
-12 Screw BH M3.0x4 (NI) E00530-040WF 1
-13 Screw NO2 PH (SW+PW) M4.0x16 (NI) E00940-160WF 1
-14 E-Ring 4.0 E60340-000F 1
-15 Screw BH M3.0x4 (NI) E00530-040WF 1
-16 Screw BH M2.0x4 (NI) E00520-040WF 3
