Citizen CL-E700 Series Technical Manual

Chapter 5 Parts Lists
CL-E700 series 5-18
PARTS LIST for CL-E700 series TITLE: Unit Head Sheet No. 1/2
Drawing No. 4 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
4-1 Bushing Head JM11201-0 2
-2 Plate Head Earth JM14105-0 1
-3 Bracket Head JM14101-0 1
-4 Guard Head Connector JM19902-0 1
-5 SA Head Cable PPS30043-0 1
-6 SA Head (200dpi) PPM80015-0 1
-7 Spring Head L JM13603-0 1
-8 SA Head Holder Base JM14704-1 1
-9 Holder Guide Sensor U JM14211-0 1
-10 Lever Head Balance JM14203-0 1
-11 Sheet Cable Protect PRA90017-0 1
-12 Spring Head R JM13602-0 1
-13 SA Lever Head Adjust 2 PPC90003-0 1
-14 Spring Head Holder PJG60051-0 1
-15 Guide Head Adjust Spring JM14204-0 1
-16 Cam Head Adjust JM19201-0 1
-17 Lever Head Adjust2 JM14202-0 1
-18 Spring Adjust Cam JM13604-0 1
-19 Cam Head Balance JM19203-0 1
-20 Pivot Head Balance Cam JM12201-0 1
