Chapter 5 Parts Lists
CL-E700 series 5-22
PARTS LIST for CL-E700 series TITLE: Unit PF Sheet No. 1/2
Drawing No. 5 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
5-1 SA PF Motor (with Thermistor) PPF80010-0 1
-2 Plate Motor Bracket PAE00039-0 1
-3 SA Main Frame L PPC60029-0 1
-4 Gear PF 1 PBF00075-0 1
-5 Gear PF Idle PBF00077-0 1
-6 Gear PF 2 PBF00076-0 1
-7 Label Mark JM99978-02 1
-8 Plate Peeler JM44105-03 1
-9 Holder Adjust Sensor L PBE00067-0 1
-10 Guide Paper Set PBM30040-0 1
-11 SA Ref Sensor PCB JM66730-10 1
-12 SA Ref Sensor Cable PPS30044-0 1
-13 Plate Adj Sen L Spring PAE00040-0 1
-14 Spring Adjust Sensor L PJG60084-0 1
-15 Spring Friction Sen PG JM23604-0 1
-16 Plate Friction PG JM24117-0 1
-17 Shaft Sensor Guide JM42008-0 1
-18 Wire Tie C6701-202# 2 8432 L=100
-19 Frame Main PAC60062-0 1
-20 SA Main Plate R JM44702-0 1
