Citizen CL-E700 Series - Page 192

Chapter 5 Parts Lists
CL-E700 series 5-26
PARTS LIST for CL-E700 series TITLE: Unit Sensor U Sheet No. 1/2
Drawing No. 6 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
6-1 SA Head Up Sensor PCB JM66715-1 1
-2 SA Head Up Sensor Cable PPS30046-0 1
-3 Cover Head Wire PBC80046-0 1
-4 Spring Sensor Frame JM23602-0 1
-5 Wire Tie C6701-202# 1 8432 L=100
-6 Cap Sensor Frame L JM24210-0 1
-7 Holder Sensor U PBE00068-0 1
-8 Cap Sensor Cable U JM24212-0 1
-9 Spring Friction Sen U JM23605-0 1
-10 SA TRA Sen PCB JM66725-0 1
-11 Tape Sensor Cable U JM24105-0 1
-12 FFC TRA Sensor PSS40016-0 1
-13 Leaf Adjust Sensor U PAG60014-0 1
-14 Plate Sensor Holder U PAC70079-0 1
-15 Cap Sensor Frame R PBH20010-0 1
-16 Sheet Cable Support A JM24114-0 1
-17 Sheet Cable Support B JM24115-0 1
-18 Screw PH M2.6x3 (NI) E00126-030WF 2
-19 Screw NO1 PHT M2.0x8 (NI) E10120-080WF 1
-20 Washer Plain 2x5x0.3 (NI) E50120-003WF 1
