Citizen CL-E700 Series Technical Manual

Chapter 1 Specifications
1-1. General Specifications
CL-E700 series 1-4
Media (continued)
Max. external diameter: 203 mm 8"
Media core internal diameter:
25 to 76 mm
1 to 3"
Min. media core external diameter (when using label media)
Outside winding: 50.8 mm 2"
On-board roll media
diameter
Inside winding: 76.0 mm 3"
Ribbon
Recommended ribbon B110A Ricoh
Max. ribbon width 114.0 mm 4.50"
Min. ribbon width 25.4 mm 1.00"
Max. ribbon length 360.0 m 1,181 ft
Max. roll diameter 74.0 mm 2.90"
Inner diameter of the
paper core
25.4  0.254 mm 1.00  0.01"
Outer diameter of the
paper core
33.4  0.50 mm 1.31  0.02"
Ribbon end tape length Max. 80.0 mm Max. 3.15"
Ribbon end detection Ribbon end detection by a ribbon encoder sensor
Bar code
For Datamax

emulation
One-dimension • Code3of9 • UPC-A • UPC-E • EAN-13 (JAN-13)
• EAN-8 (JAN-8) • Interleaved2of5 • Code128
• HIBC (Modulus 43-used code3of9) • CODABAR (NW-7)
• Int2of5 (Modulus 10-used Interleaved2of5) • Plessey
• CASE CODE • UPC2DIG ADD • UPC5DIG ADD
• Code 93 • Telepen • ZIP • UCC/EAN128
• UCC/EAN128(for K-MART) • UCC/EAN128 Random Weight
• FIM
Two-dimension • UPS Maxi Code • PDF-417 • Data Matrix • QR Code
• Aztec • GS1 DataBar
For Zebra

emulation
One-dimension • Code11 • Interleaved2of5 • Code39 • EAN-8 • UPC-E
• Code93 • Code128 • EAN-13 • Industrial2of5
• Standard2of5 • ANSI CODABAR • LOGMARS • MSI
• Plessey • UPC/EAN Extensions • UPC-A • POSTNET
• Planet
Two-dimension • Code49 • PDF-417 • CODA BLOCK • UPS Maxi Code
• Micro PDF-417 • Data Matrix • QR Code • GS1 DataBar
• TLC39 • Aztec
