Menu Menu Entry Options
MAIN RF Channel 0-7 (White RF), 1-9 (Black RF)
Select RF channel according to camin settings
RF Power (Black RF only!) Max, ½, ¼, 1/8
Select RF power. If you experience RF reception
problems in close range, try reducing RF power.
Brightness 1,2,3,4,5,6
Sets LCD brightness. While navigating through the
menu, brightness is set to default.
Factory Settings
Resets the camin to factory settings. Conrm by
pressing „Select“. Must be connected to camin when
performing factory reset.
User settings
Metadata
(camin 8M-TC only!)
O, On, CamR, Button
Controls metadata recording to USB device. On is
recording all the time, CamR is synchronised with
camera run trigger; button enables user control via the
GREEN/RED handunit buttons.
Unit Imperial, Metric
Selects measurement unit to be used and displayed on
hand unit.
Priority Cable, RF, Startup
Sets controller priority. Startup is the default, rst con-
troller to be switched on in the system gains priority.
Run Simul ON , OFF
Run Simulation: When ON, provides optical feedback
via the RUN-LED and LCD for cameras that do not
send a camera run signal. Please verify if camera is
actually running.
Stealth Mode ON , OFF
Stealth mode is used in dark environments when LEDs
cast unwanted light into a scene or are seen as reec-
tions on camera.
Boost
Camin 3M only: the boost function is activated here in-
stead of the switch on the camin 2M, 4M and 8M(+TC)
KNOB Scale Focus, Iris, Zoom, Conv, Interax, Mirror, Tilt, Rotation,
O
Assign the knob to the desired scale.
Direction left, right
Sets the knob direction. This setting is independent
from the motor direction setting, allowing to have
motors move in opposite directions while turning the
knob. See DIRECTION menu for details.
Illumina OFF, ON, 4 brightness levels
Controls knob illumination. (Only knob advanced)
Premarked OFF, ON, MET 1,2,3 IMP 1,2,3
Select premarked focus ring. Available for right or left
handed congurations
Slider
Scale Focus, Iris, Zoom, Conv, Interax, Mirror, Tilt, Rotation,
O
Select for which function the slider is used.
