Menu Menu Entry Options
Direction left, right
Sets the slider direction. This setting is independent
from the motor direction setting, allowing to have mo-
tors move in opposite directions while using the slider.
See DIRECTION menu for details.
Scale2
(With two or more sliders on
hand unit ONLY)
Focus, Iris, Zoom, Conv, Interax, Mirror, Tilt, Rotation,
O
Select for which function the slider is used.
Direction2
(With two or more sliders on
hand unit ONLY)
left, right
Sets the slider direction. This setting is independent
from the motor direction setting, allowing to have mo-
tors move in opposite directions while using the slider.
See DIRECTION menu for details.
Scale3
(With three sliders on hand
unit ONLY)
Focus, Iris, Zoom, Conv, Interax, Mirror, Tilt, Rotation,
O
Select for which function the slider is used.
Direction3
(With three sliders on hand
unit ONLY)
left, right
Sets the slider direction. This setting is independent
from the motor direction setting, allowing to have mo-
tors move in opposite directions while using the slider.
See DIRECTION menu for details.
BUTTONS Green REC, RET, UB 1, UB 2, UB 3, MARK, QSYN, RECM,
LASER, OFF
REC starts/stops the camera.
RET Trigger Return function when using an ARRI Alexa
camera and a RVI cable.
UB 1, UB 2, UB 3, triggers a camera function assigned
to a user button 1-3 on ARRI Alexa, Amira, Alexa Mini
and RED Weapon, Helium, Scarlett (in order to assign
user buttons on the camera, please refer to the corre-
sponding camera manual).
MARK is used for focus marks when used with cdis-
play and for auto focus with a cnder.
QSYN is used for quick sync. Please refer to to section
6.1.3 on page 83 for details.
RECM is used for meta data recording (camin 8M-TC
only). Please refer to section 7 on page 93.
LASER activates the laser pointer of cnder III as long
as the button is being pressed. (WARNING: Do not
point at eyes while the laser pointer is activated!)
OFF disables the button.
