Setup procedures (part 3)
9390 Reference manual
7-19
Action
Notes
2.
Enter 3431
numeral
buttons
Example of the display:
EXIT
PTT Cutout
T
imer
ENTER
T
imer:
5min
3.
To set the cutout time,
rotate
Select
Select:
•
‘
OFF
’
•
a time in the range 5–35
minutes.
4.
To save your change,
press
F2
The display shows:
EXIT
CONFIG PTT MENU
ENTER
1–T
imer
2–PTT Beep
5.
To return to Channel
mode, press three times
F1
Example of the display:
USB
HI
RF–ON
Rx.
422
Radphone
Pwr
4,128
4,420
134
136
