Codan 9390 User Manual

Link Setup mode
9-2 9390 Reference manual
Link Setup mode enter/exit
To use Link Setup mode, you have to take off the bottom
cover of the transceiver and position an internal link. When
the link is fitted, the transceiver is muted and the
PTT
button
is disabled.
SAA1064 SAA1064
IC114
IC109
1 2 3 4 A B
Parked
Link setup
This schematic shows the
location of the link on the
bottom PCB.
Figure 9.1
Moving the link for Link Setup mode
