Setup procedures (part 1)
5-26 9390 Reference manual
Clone a transceiver
This procedure copies the settings from one 9390 transceiver
to another by a process called cloning. Cloning allows you to
set up several 9390 transceivers that all work in exactly the
same way.
You clone transceivers by connecting the microphone socket
of the transceiver which is already set up to the microphone
socket of a transceiver which is to be cloned.
You can obtain the cable required for this procedure from an
authorised Codan dealer (Codan part no. 08-05138-001).
Except for the PIN and the self ID, the cloning procedure
overwrites all settings in the transceiver you are copying into.
To clone a transceiver:
Action Notes
1.
Use the Cloning cable to
join the microphone
sockets of the two
transceivers.
2.
Switch on both
transceivers.
