Appendix
11-14 9390 Reference manual
Specifications
Frequency range Transmit: 2 to 26.5MHz
Receive: 250kHz to 30MHz
Channel capacity Up to 600 channels
Operating mode Single sideband (J3E; USB–LSB)
Transmitted power
output
125 watts (PEP)
Supply voltage 12V DC nominal, negative earth
Normal operating range 10.5V to 15V DC
Maximum operating range 9V to 16V DC
Reverse polarity protection is provided.
Overvoltage
protection
Shutdown at 16V DC (nominal) for duration of overvoltage
Supply current Receive (no signal): 0.75A
Transmit J3E voice: 6A (average)
J3E two tone: 9–12A
Size and weight 9390 transceiver (excluding cradle)
Dimensions: 250mm W x 320mm D x 78mm H
Weight: 3.3kg
9391 control head (including cradle)
Dimensions: 250mm W x 70mm D x 90mm H
Weight: 0.9kg
