Appendix
11-8 9390 Reference manual
Connecting ancillary equipment
The following ancillary equipment plugs into the rear panel of
the transceiver:
• 8571 Remote control interface
• 9300 ALE controller
• 9366 control head
• automatic antenna and antenna tuner
• computer
• data and fax modem
• external alarm
• GPS receiver
• IPC-500 telephone interconnect.
The following table shows the connections on the transceiver
rear panel for ancillary equipment.
Equipment connected to either the
RS232
socket or
GP
connector on the transceiver rear panel is controlled by the
transceiver’s RS-232 and baud rate settings. See Chapter 7,
RS-232 connected equipment and RS-232 connection baud
rate.
If you want to connect a combination of ALE controllers,
modems, GPS receivers and computers, you will need to use
the optional RS-232/I
2
C Interface described on page 11-10.
