Installation
9390 Reference manual 2-3
Ship station
A ship station typically consists of a DC power supply
(battery) connected to the transceiver. A coaxial cable
connects the transceiver to an antenna tuning unit which is
attached to a whip or long wire antenna.
The transceiver and microphone should be mounted in such a
way as to be easily accessible to the operator.
24V to
12V
inverter
Microphone
Transceiver
Whip or long
wire antenna
On/Off
Select
Mode
Scan
S'Call
Mute
Voice
Mute
On/Off Mode
Tune
F2F1
Volume
9390 Marine Transceiver
CODAN
Test
2182
AM /SSB
Emgcy
Call
+
24V
battery
either / or
+
12V
battery
9103 or 4203
antenna
tuner
Figure 2.2
A typical ship station installation
