Installation
9390 Reference manual 2-7
Installing the control head
Make sure that the transceiver is disconnected from the DC
power source before connecting the control head to the
Remote Control
connector on the transceiver.
Mounting the cradle and control head
To mount the cradle and control head:
1. Select a suitable location to mount the control head.
Avoid places exposed to direct sunlight.
2. Remove the two cradle screws and washers securing the
cradle to the control head.
3. Secure the cradle into position. Ensure that there is
sufficient space at the rear for the cables.
4. Secure the control head to the cradle with the two screws
and washers.
