Link Setup mode
9390 Reference manual 9-3
To use Link Setup mode:
Action Notes
1.
Ensure the transceiver is
switched off.
2.
Remove the bottom cover
by removing the screws on
either side and lifting the
cover off.
The bottom cover usually has
four rubber feet fitted.
3.
Locate the link shown in
Figure 9.1 and move it to
the Link setup position.
The link is a small connector
that slides over two pins on the
board.
Pull it up gently to remove it.
4.
Switch on the transceiver. The display shows:
LINK SETUP MENU
1–Pin
2–Inhibit
ENTER
3–Antenna
4–Reset
The transceiver only detects a
changed link position when the
transceiver is first switched on.
5.
Follow one of the Link
Setup procedures to make
your changes.
See the Link Setup procedures
later in this chapter.
When all procedures have been
completed continue with
Step 6–8.
