Changing the setup options
9480 HF SSB transceiver Error! Main Document Only.-3
Changing the position of the front panel link
The front panel link is a black plastic moulding incorporating linked metal contacts.
The contacts short together pins located on the front panel display PCB.
Extreme care should be taken when handling the
transceiver to prevent damage to the components.
Step Action
1.
Turn the transceiver off and disconnect the power.
2.
Remove either:
• the bottom cover of front panel control transceivers
• the control head rear panel of extended control head
transceivers.
3.
Make a note of the position you found the link (E or F).
Move the front panel link from position F (front panel
control) or E (extended control head) to position 1.
4.
You can now carry out the relevant set-up procedures.
5.
After completing the set-up procedures, turn the transceiver
off and disconnect the power before returning the link to its
original position.
6.
Replace the cover before reconnecting the power to your
transceiver. Your transceiver is now ready for normal use.
