Changing the setup options
Error! Main Document Only.-4 9480 HF SSB transceiver
The microprocessor PCB link
The microprocessor link is one that you will have to make and
solder on the microprocessor PCB positioned on the underside
of the transceiver (Figure 8.2).
The link must only be soldered across the number 2 pads (called
the inhibit link). A link soldered across the number 2 pads
prevents you from changing the inhibit setup options on channel
programming.
Microprocessor link
12
3
4
Figure 8.2: The microprocessor link
