Changing the setup options
9480 HF SSB transceiver Error! Main Document Only.-5
Inserting the microprocessor PCB link
Extreme care should be taken when handling the
transceiver to prevent damage to the components.
This procedure must only be carried out by a qualified
technician.
Step Action
1.
Turn the transceiver off and disconnect the power.
2.
Lay the transceiver on its top with the front panel facing
you.
3.
Remove the bottom cover of the transceiver.
4.
Locate the microprocessor PCB and the number 2 pads
(refer to page 8-4). The link must only be fitted across the
number 2 pads. Number 1, 3 and 4 pads are not used.
5.
Solder a suitable piece of wire across the number 2 pads
(the Inhibit link).
6.
Carry out the relevant setup procedures.
7.
After completing the setup procedure, turn the transceiver
off and disconnect the power before removing the link.
8.
Replace the cover before reconnecting the power to the
transceiver. The transceiver is now ready for normal use.
